Vsol V2802DAC XPON 2GE WiFi5 Dual Band Onu Router

Original price was: 3,500.00৳ .Current price is: 3,199.00৳ .

Brand: VSOL
🌙 Order now, shipped tomorrow
  • Dual Band AC Series Wireless Router
  • Loop Detection & Auto-Prevention
  • Supports IPv4/IPv6 Dual Stack
  • Supports SIP Protoco
  Estimated Delivery: Fri, Oct 02 – Sat, Oct 03
  ... people are viewing this right now

  Share

2GE+AC WiFi ONU terminal devices are designed for fulfilling FTTH and triple play service demand of fixed network operators. These boxes are based on the mature Chipset (Realtek) technology, which have high ratio of performance to price, and the technology of IEEE802.11b/g/n/ac WiFi, Layer 2/3, and high quality VoIP as well. Support full management of HGU devices through VSOL OLT. They are highly reliable and easy to maintain, with guaranteed QoS for different services.

Technical item 2GE+AC WiFi ONU
PON interface 1 G/EPON port(EPON PX20+ and GPON Class B+)
Receiving sensitivity: ≤-28dBm Transmitting optical power: 0~+4dBm
Transmission distance: 20KM
Wavelength Tx1310nm,Rx 1490nm
Optical interface SC/UPC connector
LAN interface 2 x 10/100/1000Mbps auto adaptive Ethernet
interfaces, Full/Half, RJ45 connector
WiFi interface Compliant with IEEE802.11b/g/n/ac
2.4GHz Operating frequency: 2.400-2.483GHz 5.0GHz Operating frequency: 5.150-5.825GHz
Support MIMO, 4T4R,5dBi external antenna, rate up to 1.167Gbps
Support: multiple SSID
TX power: 11n–22dBm/11ac–24dBm
LED 9, For Status of POWER、LOS、PON、WAN、 LAN1、LAN2、2.4G、5G、PHONE
Operating
condition
Temperature: 0℃~+50℃
Humidity: 10%~90%(non-condensing)
Storing condition
Temperature: -30℃~+60℃
Humidity: 10%~90%(non-condensing)
Power adapter DC 12V/1.5A or DC12V/1.0A
Power supply ≤10W
Dimension 185mm×120mm×34m(L×W×H)
Net weight 0.32Kg
○ Hardware Parameter
Dimension 178mm×120mm×30mm(L×W×H)
Net weight 0.31Kg
Operating condition Operating temp: -10 ~ +55°C Operating humidity: 5 ~ 95%  (non-condensed)
Storing condition Storing temp: -40 ~ +70°C Storing humidity: 5 ~ 95%  (non-condensed)
Power adapter DC 12V,1.0A, external AC-DC power adaptor
Power supply ≤12W
Interface 1GE(WAN/LAN1)+1GE(LAN)+Wi-Fi 5
Indicators PWR, PON, LOS, WAN, LAN1, LAN2, 2.4G, 5G
○ Interface parameter
PON interface
  • 1XPON port(EPON PX20+ and GPON Class B+)
  • SC single mode, SC/UPC connector
  • TX optical power: 0~+4dBm
  • RX sensitivity: -27dBm
  • Overload optical power: -3dBm(EPON) or  -8dBm (GPON)
  • Transmission distance: 20KM
  • Wavelength: TX 1310nm, RX1490nm
User interface 2×GE, Auto-negotiation,RJ45 ports
WLAN interface
  • Compliant with IEEE802.11b/g/n/ac
  • 2.4GHz Operating frequency: 2.4000-2.4835GHz
  • 5.0GHz Operating frequency: 5.150-5.825GHz
  • Support MIMO, rate up to 1.167Gbps
  • Wi-Fi: 2.4GHz( 2T2R ), 5.8GHz( 2T2R ), 5dBi antenna, support: multiple SSID
  • TX power: 11n–22dBm/11ac–24dBm
○ Function Data
Management
  • OAM/OMCI, Telnet, WEB, TR069
  • Support full management of ONT functions by VSOL OLT
Internet connection Support Bridge, Route and  Bridge/Route mixed mode
Multicast
  • Support IGMP v1/v2/v3
  • Support IGMP Proxy and MLD Proxy
  • Support IGMP Snooping and MLD  Snooping
VLAN
  • Support VLAN tag mode
  • Support VLAN trunk mode
  • Support VLAN translation
Data Service Functions
  • Full speed non-blocking switching
  • 2K MAC address table
  • 8 full range VLAN ID
  • Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc
  • Support auto polarity detection of Ethernet ports (AUTO MDIX)
  • Integrated IEEE802.1p QoS with four level priority queues
  • Support IGMP v1/v2/v3 snooping/proxy and MLD v1/v2 snooping/proxy
Wireless
  • Support Wireless AP mode
  • Support 802.11 b/g/n/ac
  • Support Multiple SSID
  • Authentication : WEP/WAP-PSK(TKIP)/WAP2-PSK(AES)
  • Modulation type: DSSS, CCK and OFDM
  • Encoding scheme: BPSK, QPSK, 16QAM and 64QAM, 256QAM
  • Support EasyMesh protocol
QoS
  • Support 4 queues
  • Support SP and WRR
  • Support 802.1P and DSCP
L3
  • Support IPv4, IPv6 and IPv4/IPv6 dual stack
  • Support DHCP/PPPOE/Static
  • Support Static route
  • Support DHCP Server
  • Support NAT/DMZ/DDNS
  • Support Virtual Server
Security
  • Support Firewall
  • Support Mac filter Based on MAC or URL
  • Support ACL
